- Covered Rated Speeds: ≤0.63m/s; 1.0m/s; 1.5~1.6m/s; 1.75m/s
- Sheave Pitch Diameter: φ200mm
- Steel Wire Rope Diameter: φ6mm
- Lifting Force: ≥500N
- Tensioning Device: Matched as standard, no selection required
- Power Supply Voltage: Standard AC220V, Optional DC24V
- Working Position: Car Side or Counterweight Side
- Upward Control: Permanent Magnet Synchronous Traction Machine Brake, Counterweight Safety Gear
- Downward Control: Safety Gear
- Remote Operation: Supports electrically controlled test operation and electric switch reset; mechanical part automatic reset
Overspeed signal is connected to the safety circuit. Connect the power supply to the electromagnet for switch reset and test operation in accordance with the coil voltage requirement.
